ANTILENG Remakes American KRELL KSA50 Class A Rear Grade High Grade Hifi Audio Amplifier
Product Introduction
Our store has replicated this KSA50, with a one-to-one circuit from the original KSA50. The main tube uses a triple Ken high-power tube A1216 C2922, and one channel has three pairs of main tubes. The thrust is much greater than the original machine's 2 pairs of gold sealed tubes ON 15003 15004, and the high frequency is more delicate.
1. Highlight - The feedback capacitor uses the same German ROE adhesive wood capacitor as the original machine.
2. Highlight - Toshiba A968 C2239 adopts the original black and green color scheme.
3. Static current of 400MA per tube.
4. Pure Class A per channel: 50W 8 Ω, 100W4 Ω.
5: The total filtering capacitor capacity is 160000 UF. Two identical power boards are stacked on top and bottom.
6: 1000W transformer.
7: Machine size: 480 wide, 224 high, 450 deep, including handle and horn post (mm).
8: Voltage: 115V/220V 50-60HZ.
9: Total harmonic distortion: 0.035%.
10: Signal to noise ratio: 100DB.
11: Frequency response: 20-20KHz.
12: Weight approximately: 35KG
$1,499.00
